Price:
Model Number: DFLSX1200-13S
Power: 55KW&22KW
Application: curbstone cutting
Weight: 20T
Brand Name: DAFON
Certification: CE, ISO
Packaging logistics: In wooded cases with fumigation finish or wrapped with plastic film.
Kerb Stone Cutting Machine Features:
1. no cement foundation needed, easy installation and shipment(40’’ HQ).
2. the main shaft adopts high frequency modulation treatment, which will be more durable and wear-resisting.
3. kerb stone cutter uses main spindle and a vice spindle to seal all saw blades together which can ensure the machine stable while cutting hard granite.
4. it uses a simple program of movement on the controlling box, easy for setting, operating, and maintaining.
5. Kerb Stone Cutting Machine adopts two hydraulic pillars(a set of hydraulic systems) on both sides of the machine to ensure the strength of cutting spindle lifting up and down.
6. Unlike traditional stone cutting, it dramatically increases productivity and reduces labor cost and power consumption and it consumes less diamond segment per cubic meter of production compared to the traditional cutting machine.
7. Cast iron is adopted in the main frame of the machine to make the machine more stable with less chance of vibration under the operating condition.
8. The regular worktable length of the shaft is 1.6m(1.8m optional)
Technical data:
Complete Machine Line (1 Edge Cutting Machine + 1 Slicing Machine) |
||||
Slicing Machine DF1200-12S |
|
Edge Cutting Machine DF1200-1S |
||
Dimension |
6000×3000×2800mm |
|
Dimension |
6000×4000×4500mm |
Diameter of blade |
1200mm |
|
Diameter of blade |
1200mm |
Number of blades |
12pcs |
|
Number of blades |
1pcs |
Max.cutting size |
3000×1800×450mm |
|
Worktable size |
2500×1800mm |
Worktable size |
2500×1800mm |
|
Working length max |
2500mm |
Weight |
10t |
|
Max.vertical stroke |
600mm |
Max.cutting depth |
450mm |
|
Weight |
9t |
Main motor power |
55kw-6 |
|
Max.cutting depth |
450mm |
Max.vertical stroke |
600mm |
|
Main motor power |
22kw-6 |
It produces about 30-35m³ of stone every day (24h) and covers a total space of 12m*5m. |
How is the cutting efficiency of automatic kerbstone cutting machine?
Automatic kerbstone cutting machine is a kind of efficient and intelligent cutting equipment, which can process various types and sizes of kerbstones, and the cutting efficiency is very high. Compared with traditional manual cutting, the processing speed of automatic roadside stone cutting machine can be increased at least several times, which not only saves time, but also greatly reduces the labour cost. At the same time, automatic roadside stone cutting machine has a compact structure, easy to operate, easy to switch and so on, it is very convenient to use.
The automatic kerbstone cutting machine adopts a high-precision control system, which is able to implement high-precision cutting and processing, with an accuracy of up to millimetre level. The cutting efficiency and precision are very high, which is incomparable to traditional manual cutting. The automatic kerbstone cutting machine adopts advanced technology with automatic sensing, high precision, automatic correction and other functions, which not only ensures the precision of cutting, but also avoids cutting errors and ensures the quality of each piece of kerbstone.
Therefore, it can be said that the cutting efficiency of automatic curbstone cutting machine is very high, especially suitable for mass production and processing. In modern architecture, more and more designers and architects have higher and higher requirements for the design and style of kerbstones, therefore, the appearance of automatic kerbstone cutter is undoubtedly a kind of "tool", which allows designers and architects to better realise their own design concepts and thinking.
