Price:
Brand Name: DAFON
Certification: CE, ISO
Model Number:
Power: 11*3KW
Weight: 5000kg
Application: can process special-shaped stone products such as columns, balustrade, flower pots, etc.
Place of Origin: CHINA.
Trading Method: FOB/CIF/EXW Xiamen Port
Minimum Order Quantity: 1 SET
Delivery Time:90 Days
Packaging logistics: In wooded cases with fumigation finish or wrapped with plastic film.
Features:
Multi-purpose advantage of one machine:
Can not only process the column but can also process the diameter of less than 600 stone balls, reducing repeated investment
Transmission structure advantage:
Completely solve the traditional vertical model, the transmission is easy to break, maintenance is difficult, and maintenance costs are expensive.
Adopt whole casting worm gearbox: The turbine and worm gear are completely immersed in oil, have reliable operation, and have a very low failure rate.
Advantage of frame structure:
Higher strength frame, not easy to be deformed in long-term use.
Double-sided rail column saw blade, and thimble with the same column, better precision of up and down lift
Speed advantage:
Processing a set of railings 20-30min, 6 balusters at a time, high processing efficiency
Advantages of advanced electric control:
PLC and CNC systems can be chosen to optimize the processing action, profiling efficiency is higher, with railings, balls, and cylinders automatically cut back to the boarding function, more practical
Specification:
|
|
Unite | 6heads | 4 heads | big 4 heads |
|
Maximum machining diameter |
mm | 200/6pcs,500/3pcs | 500/4pcs | 700/4pcs |
|
Center distance |
mm |
315 | 650 | 1000 |
|
Maximum processing length |
mm | 1350 | 1000 | 1000 |
|
Diameter of saw blade |
mm | 600 | 600 | 600 |
|
Main motor power |
kw | 11*3 | 11*4 | 11*4 |
|
Weight of main motor |
kg | 5000 | 6000 | 7000 |
|
Overall Dimension |
mm | 3600*1800*3200 | 4500*1800*3200 | 6000*1800*3200 |
CNC router and profiling machine features : 1. Using CNC system control, deeper custom development of stone cutting, simple and easy to use software, rich functions, suitable for ...
Introduction: The Balustrade Profiling Machine, also known as the Stone Baluster Profiling Machine, adopts a gantry structure: it is convenient for loading and unloading of stone...
Solid column profiling machine, with microcomputer control, compact structure, and convenient operation, is an efficient tool in the field of stone processing. It is specially desi...
Features: Multi-purpose advantage of one machine: Can not only process the column, more can process the diameter of less than 600 blocking ball, reduce repeated investment Transm...
