Price:
Model Number: DFMJ-16C-24C
Power: Depends on heads no.
Application: Art & Craft, Stone Industry
Weight: Depends on head quantity
Brand Name: DAFON
Certification: CE, ISO
Packaging logistics: In wooded cases with fumigation finish or wrapped with plastic film.
Techinical Data
|
Name |
Unit |
DF-16T |
|
Maximum grinding plate width |
mm |
2000 |
|
Crossbeam swing speed |
m/min |
3-35 |
|
Cross beam drive motor |
kw |
2x4 |
|
Belt drive speed |
m/min |
0.5-4 |
|
Belt drive power |
kw |
4 |
|
main motor power |
kw |
16x15 |
|
Number of grinding heads |
pcs |
16 |
|
Grinding disc diameter |
mm |
φ500 |
|
cooling water pressure |
Mpa |
0.1-0.15 |
|
compressed air |
Mpa |
≥0.7 |
|
Host size |
mm |
11500x3960x2600 |
|
Host total power |
kw |
252 |
