Price:
Brand Name: DAFON
Model Number: DFL-SD1200
Power: 22KW
Application: Art & Craft, Stone Industry
Weight: 9000kg
Place of Origin: CHINA.
Trading Method: FOB/CIF/EXW Xiamen Port
Certification: CE, ISO
Minimum Order Quantity: 1 SET
Delivery Time:90 Days
Packaging logistics: In wooded cases with fumigation finish or wrapped with plastic film.
Problems encountered by customers:
During the cutting process of traditional single trolley stone cutting machine, there are problems such as long loading and unloading time, low efficiency, and high equipment investment. In order to help customers solve these problems, we have proposed a solution of double trolley stone cutting machine
Dafon’s solution:
The core of the concept is to add a trolley and stagger the work with the original trolley. When one trolley is cutting kerb stones, another trolley can load or unload stones, reducing the time spent on loading or unloading and greatly improving work efficiency.
Benefits of using Kerbstone Edge Cutting Machine with Double Trolley :
1. Improve work efficiency: the staggered work of double trolleys can reduce the loading and unloading time from 50% to 25% of the traditional single trolley, thus increasing the overall work efficiency by more than 25%.
2. Saving equipment investment: Compared with the traditional curb stone cutting machine, the design only needs to add one dolly to realize the same function, thus reducing the capital investment of equipment by 20%~30%.
3. Improve safety: Since the loading and unloading operation is carried out on a non-desk trolley, safety accidents caused by loading and unloading can be effectively avoided.
Applicable enterprises:
1. There is not enough space to install the production line of stone production enterprises
2. Small stone processing enterprises that are cash-strapped and unable to invest in too much equipment
The innovation of Dafon's Solution:
1. Optimization of the production process: double trolleys, cleverly separating cutting, and loading/unloading.
2. Saving cost and space: improve working efficiency, reduce energy consumption, save cost and occupy space.
3. Humanization: Reduces the work intensity of the work and improves the safety of loading and unloading materials
Technical Parameters
Name | Unit |
|
Size (L*W*H) | mm | 12000*4200*4600 |
Max.saw blade diamater |
mm |
1200 |
Max.number of saw blades |
pcs | 1 |
Spindle diameter |
mm | 50 |
Max. loading size | mm | 2700*1700*450 |
Main motor power |
kw | 22 |
Weight | kg | 9000 |
L-shaped Kerb stone : suitable for road edges, which can effectively guide the walking direction of vehicles and pedestrians. U-shaped Kerb stone : suitable for side...
T-shaped Kerb stone: often used in traffic islands, pedestrian bridges and other places to prevent vehicles from crossing illegally. ...
U-shaped Kerb stone: suitable for sidewalks or public squares, etc. Its curved design helps improve pedestrian safety and comfort. ...
Machinepart The machine line included one slicing machine(DF1200-12S) and one edge cutting machine(DF1200-1S), worker load thick slab to the slicing machine with a crane, after s...
The introduction ofautomatic stone cutting machine This kerbstone cutting machine line is mainly for cutting slab width above 50mm, the machine cut with 10-14pcs of blade at the ...
Granite kerbstone cutting machine included one slicing machine(DF1200-12S) and one edge cutting machine(DF1200-1S), worker load thick slab to the slicing machine with a crane, afte...
